About File Transmission Setting

This function sends the RIPed data to the host (SMB server) registered on this machine by using the PS Plug-in driver or Hot Folder. Once the RIPed data is saved, it can be used for digital inspection (comparison of data before and after RIP) and other purposes.

This screen is displayed if you select File Transmission Setting in the Controller Machine Setting Menu screen. For details about how to display the Controller Machine Setting Menu screen, refer to Overview of Controller.

Tips

If No. 137 is set to "1" (ON) in Utility/Counter - Administrator Setting - Controller - Software Switch Setting, File Transmission Setting is displayed. For details about how to operate the software switch, refer to [Software Switch Setting].

Name	Description
1 to 10	The RIPed data is transferred to the host (SMB server) registered on this machine.
